T5 adaptor with reflector from China manufacturer - New Lights(Haining) Lighting Co.,Ltd.

Price:	1.98~9.34 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU,
Place of Origin:	Zhejiang, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: T851007

Production Capacity: 2000pcs /day

Delivery Date: 15-25days

Principle: CFL

Certificate: CE RoHs

THD: 10%

Watts: 14W,21W,28W,35W,49W

Means of Transport: Ocean,Land,Air,

Packing: box

Shape: Straight

Brand Name: XGY

Voltage: 96-260V

Power factor: 0.99

Size: 2ft,3ft,4ft,5ft

T5 adaptor with reflector
1.save 40% energy
2.Environmentally friendly
3.Lifetime 30000 hours.
4.TUV/CE ENEC approved.

T5 adaptor with reflector

Product Advantages:

The T5 Adaptor Kit is a complete conversion system that can be used to directly replace the existing T8, or T10, or T12 Lamp with electromagnetic ballast.

-Up to 45% energy saving over equivalent T8 lamps and more for T10 or T12 lamps;

-Direct retro-fit for T8, or T10, or T12 lamps, no electrician required;

-At least 10% extra lumen output compared with T8, or T10, or T12 lamps;

-No flickers and better CRI;

-Compact concise appearance and easy installation

Product Features:

-0.35mm Thick Aluminum Body Material with small reflector, choice of white powder coated, or luster, or matte

-PC Anti-Flaming Lamp Holder

-Nano-meter Anti-oxidation Film;

-T5 Tri-phosphor Tube Included, choice of 10,000h or 20,000h

-Horizontal and Vertical Installations

-Protection Class II

Ballast Available:

-Voltage Choice Available:

Ø 220-240V, 50/60Hz

Ø 110-120V, 50/60Hz

Ø 90-260V, 50/60Hz

-Ballast Parameters Available:

Ø IC Standard Ballast, PF≥0.99, THD≤10%, Life = 30,000 hours, TUV CE, CB, GS, ENEC, UL Certified;

Ø TUV Standard Ballast, PF≥0.98, THD≤15%, Life = 20,000 hours, TUV CE Certified;

Ø Normal High Standard Ballast, PF≥0.95, THD≤30%, Life = 15,000 hours, Pass EMC and LVD Testing;

Ø Normal Low Standard Ballast, PF≥0.55, THD≤130%, Life = 15,000hours, Pass EMC and LVD Testing;

Instructions

-1) Turn off the power; 2) Remove the T8 tube and starter; 3) Install the T5 adaptor kit; 4) Switch on

Packing:

1)One piece in one polybag;

2)One polybag in a individual carton

3)25pcs in a standard export carton

Wattage	Replace T8 Tubes	Feet	Color Temp.	Lumens (lm)	Length (mm)	Width (mm)	Depth (mm)	Operation Temp.[1]	PCS/ CTN	Packing Size(cm)
T5 14W	T8 18W	2ft	2700K-6500K	1020-1150	590	36	42	-10 to 50℃	25	6524.525
T5 21W	T8 30W	3ft	2700K-6500K	1530-1800	895	36	42	-10 to 50℃	25	9524.525
T5 28W	T8 36W	4ft	2700K-6500K	1620-2450	1199	36	42	-10 to 50℃	25	12524.525
T5 35W	T8 58W	5ft	2700K-6500K	2250-3240	1500	36	42	-10 to 50℃	25	15524.525
